Harsh Flanges is a reputable manufacturer and supplier of St37-2 Flanges, located in Mumbai, India. We’re recognized for our precision engineering and unwavering commitment to quality. Our flanges, crafted from St37-2—a popular carbon structural steel—are valued for their excellent weldability, toughness, and affordability. This makes them perfect for a wide array of general construction and piping applications. Thanks to our advanced manufacturing techniques and rigorous quality checks, we deliver reliable and high-performing flange solutions. With a robust supply chain and a dedication to customer satisfaction, Harsh Flanges proudly serves clients throughout India and beyond with trustworthy flange products.
St37-2 is a low-carbon structural steel that meets DIN 17100 standards. Its typical chemical makeup includes about 0.17% carbon, 1.40% manganese, along with trace amounts of phosphorus and sulfur. St37-2 boasts impressive mechanical properties, featuring a tensile strength of 470–630 MPa, a yield strength of around 235 MPa, and an elongation of 20–25%. Its excellent weldability and machinability make it perfect for forming, bending, and fabrication. While it’s not heat-treatable for high strength, it remains a solid choice for moderate-load applications due to its balanced strength, ductility, and ease of processing.
Harsh Flanges, a leading supplier in Mumbai, India, offers an extensive selection of St37-2 Flange, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards | API7S-15, API7S-43, API605, ANSI/ASME B16.5, B16.47 Series A & B, B16.48, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, EN1092 |
| Pressure Rating ANSI | 600 LBS, 900 LBS, 150 LBS, 2500 LBS, 300 LBS, 1500 LBS |
| Pressure Calculation in DIN | 16Bar 6Bar 25Bar 40Bar 10Bar / PN10 PN16 PN6 PN25 PN64 PN40 |
| JIS | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Anti-rust Paint, Zinc Plated,Oil Black Paint, Cold and Hot Dip Galvanized, Yellow Transparent |
| Most common types | Forged / Threaded / Screwed / Plate |
| Steel grade | Styles | Carbon, max, % | Silicon, % | Manganese, % | Phosphorus, max, % | Sulfur, max, % | Nitrogen, max, % |
| ST37-2 | Steel Angles | 0.20 | 0.15 – 0.35 | 0.35 – 0.75 | 0.050 | 0.050 | 0.011 |
| Steel grade | Styles | Tensile strength, ksi [MPa] | Yield point, min, ksi [MPa] | Elongation, min, δ, % |
| ST37-2 | Steel Angles | 52 – 67 [360 – 460] | 34 [235] | 25 |
St37-2 Flanges are widely used in general construction, machinery fabrication, and pipeline systems, thanks to their strength, ductility, and ease of welding. They’re ideal for structural frameworks, bridges, support columns, and industrial piping systems where high mechanical loads aren’t a primary concern. In manufacturing, these flanges connect pipelines, valves, pumps, and other equipment across various industries, including construction, water treatment, and transportation. Their cost-effectiveness and reliable performance under standard temperature and pressure conditions make St37-2 flanges a go-to choice for infrastructure and engineering projects around the globe.
Yes, we offer custom sizes for St37-2 Flange to meet specific project needs. Our team at Harsh Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@harshflanges.co.in.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
