Harsh Flanges is a well-respected manufacturer and supplier of DIN 2631 PN6 Weld Neck Flanges, based in Mumbai, India. They specialize in precision-engineered flange solutions that adhere to DIN standards for low-pressure applications. With a strong commitment to quality, durability, and international compliance, Harsh Flanges delivers weld neck flanges that guarantee secure, leak-proof connections across various industrial piping systems. These flanges are designed for long-lasting performance and seamless integration, making them perfect for fluid and gas systems operating at 6 bar pressure. Harsh Flanges caters to a diverse array of industries, including water treatment, chemicals, HVAC, and food processing, both domestically and globally.
Typically, DIN 2631 PN6 Weld Neck Flanges are crafted from materials like carbon steel, stainless steel, or alloy steel, depending on the specific application needs. They consist of elements such as iron, carbon, chromium, and nickel, which contribute to their impressive mechanical performance. These flanges usually boast tensile strengths ranging from 400 to 600 MPa and yield strengths between 250 and 350 MPa. Designed to handle a nominal pressure of 6 bar, they are recognized for their excellent weldability, corrosion resistance, and structural integrity in low-pressure environments.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Pipe | Flange | Neck | Raised face | Screws | Weight | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (7,85 Kg/dm3) | ||||||||||||||||
| Rated | d1 | D | b | k | h1 | d3 | s | r | h2 | d4 | f | Holes | Thread | d2 | Kg | |
| Diameter | ISO Series | DIN Series | ||||||||||||||
| 15 | – | 20 | 80 | 12 | 55 | 30 | 28 | 2 | 4 | 6 | 40 | 2 | 4 | M 10 | 11 | 0,392 |
| 21,3 | – | 30 | ||||||||||||||
| 20 | – | 25 | 90 | 14 | 65 | 32 | 35 | 2,3 | 4 | 6 | 50 | 2 | 4 | M 10 | 11 | 0,592 |
| 26,9 | – | 38 | ||||||||||||||
| 25 | – | 30 | 100 | 14 | 75 | 35 | 40 | 2,6 | 4 | 6 | 60 | 2 | 4 | M 10 | 11 | 0,747 |
| 33,7 | – | 42 | ||||||||||||||
| 32 | – | 38 | 120 | 14 | 90 | 35 | 50 | 2,6 | 6 | 6 | 70 | 2 | 4 | M 12 | 14 | 1,05 |
| 42,4 | – | 55 | ||||||||||||||
| 40 | – | 44,5 | 130 | 14 | 100 | 38 | 58 | 2,6 | 6 | 7 | 80 | 3 | 4 | M 12 | 14 | 1,18 |
| 48,3 | – | 62 | ||||||||||||||
| 50 | – | 57 | 140 | 14 | 110 | 38 | 70 | 2,9 | 6 | 8 | 90 | 3 | 4 | M 12 | 14 | 1,34 |
| 60,3 | – | 74 | ||||||||||||||
| 65 | 76,1 | – | 160 | 14 | 130 | 38 | 88 | 2,9 | 6 | 9 | 110 | 3 | 4 | M 12 | 14 | 1,67 |
| 80 | 88,9 | – | 190 | 16 | 150 | 42 | 102 | 3,2 | 8 | 10 | 128 | 3 | 4 | M 16 | 18 | 2,71 |
| 100 | – | 108 | 210 | 16 | 170 | 45 | 122 | 3,6 | 8 | 10 | 148 | 3 | 4 | M 16 | 18 | 3,24 |
| 114,3 | 130 | |||||||||||||||
| 125 | – | 133 | 240 | 18 | 200 | 48 | 148 | 4 | 8 | 10 | 178 | 3 | 8 | M 16 | 18 | 4,49 |
| 139,7 | – | 155 | ||||||||||||||
| 150 | – | 159 | 265 | 18 | 225 | 48 | 172 | 4,5 | 10 | 12 | 202 | 3 | 8 | M 16 | 18 | 5,15 |
| 168,3 | – | 184 | ||||||||||||||
| 200 | 219,1 | – | 320 | 20 | 280 | 55 | 236 | 5,9 | 10 | 15 | 258 | 3 | 8 | M 16 | 18 | 7,78 |
| 250 | – | 267 | 375 | 22 | 335 | 60 | 282 | 6,3 | 12 | 15 | 312 | 3 | 12 | M 16 | 18 | 10,8 |
| 273 | – | 290 | ||||||||||||||
| 300 | 323,9 | – | 440 | 22 | 395 | 62 | 342 | 7,1 | 15 | 15 | 365 | 4 | 12 | M 20 | 22 | 14 |
| 350 | 355,6 | – | 490 | 22 | 445 | 62 | 385 | 7,1 | 12 | 15 | 415 | 4 | 12 | M 20 | 22 | 18,5 |
| – | 368 | 16,7 | ||||||||||||||
| 400 | 406,4 | – | 540 | 22 | 495 | 65 | 438 | 7,1 | 12 | 15 | 465 | 4 | 16 | M 20 | 22 | 21,2 |
| – | 419 | 19 | ||||||||||||||
| 500 | 508 | – | 645 | 24 | 600 | 68 | 538 | 7,1 | 12 | 15 | 570 | 4 | 20 | M 20 | 22 | 28,6 |
| 600 | 610 | – | 755 | 24 | 705 | 70 | 640 | 7,1 | 12 | 16 | 670 | 5 | 20 | M 24 | 26 | 31,5 |
| 700 | 711 | – | 860 | 24 | 810 | 70 | 740 | 7,1 | 12 | 16 | 775 | 5 | 24 | M 24 | 26 | 37,4 |
| 800 | 813 | – | 975 | 24 | 920 | 70 | 842 | 7,1 | 12 | 16 | 880 | 5 | 24 | M 27 | 30 | 46,1 |
| 900 | 914 | – | 1075 | 26 | 1020 | 70 | 942 | 7,1 | 12 | 16 | 980 | 5 | 24 | M 27 | 30 | 55,6 |
| 1000 | 1016 | – | 1175 | 26 | 1120 | 70 | 1045 | 7,1 | 16 | 16 | 1080 | 5 | 28 | M 27 | 30 | 61,9 |
Harsh Flanges, a leading supplier in Mumbai, India, offers an extensive selection of DIN 2631 PN6 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2631 PN6 Weld Neck Flanges are commonly utilized in industries that demand reliable and durable connections for low-pressure piping systems. Typical applications include water distribution, HVAC systems, chemical pipelines, food and beverage processing, and general industrial infrastructure. These flanges are favored for their ability to provide a smooth flow path, minimize turbulence, and effectively transfer stress from the flange to the pipe. Their weld neck design makes them ideal for high-integrity applications where factors like thermal expansion, vibration, or bending stresses can impact system performance.
Yes, we offer custom sizes for DIN 2631 PN6 Weld Neck Flanges to meet specific project needs. Our team at Harsh Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@harshflanges.co.in.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| Nickel Alloy DIN 2631 PN6 Welding Neck Flange | Mild Steel DIN 2631 PN6 Weld Neck Flange |
| Carbon Steel DIN 2631 PN6 Welding Neck Flange | DIN 2631 PN6 Weld Neck RF Flange Supplier in India |
| DIN 2631 PN6 Weld Neck Flange Dimensions | Raised Face DIN 2631 PN6 Weld Neck Flange Manufacturer |
| 18 inch DIN 2631 PN6 Carbon Steel Weld Neck Flange | DIN 2631 PN6 Weld Neck Flange Dimensions in mm |
| Alloy Steel DIN 2631 PN6 Welding Neck Flanges | Copper Nickel DIN 2631 PN6 Weld Neck Flanges at Best Price |
| DIN 2631 PN6 Welding Neck FF Flange Supplier | Suppliers of DIN 2631 PN6 Weld Neck Flange |
| German Standard DIN 2631 PN6 Weld Neck Flanges | DIN 2631 PN6 Weld Neck Flange Supplier in Mumbai
|
| DIN 2631 PN6 Weld Neck Flange Manufacturer | Flat Face DIN 2631 PN6 Weld Neck Flange Manufacturer |
| DIN 2631 PN6 WNRF Flange Stockist in India | Raised Faced DIN 2631 PN6 welding-neck flanges Dealer in India |
| Stainless Steel DIN 2631 PN6 Weld Neck Flange | ASTM B564 Raised Faced DIN 2631 PN6 Weld Neck Flanges |
| DIN 2631 PN6 WNRF Flange Exporter | DIN 2631 PN6 Weld Neck Flange Pressure Ratings |
| Raised Face DIN 2631 PN6 Weld Neck Plate Flanges | Titanium DIN 2631 PN6 Welding Neck Flanges |
| DIN 2631 PN6 WNRF Flanges Supplier in Mumbai | Alloy Steel DIN 2631 PN6 Weld Neck Flanges Manufacturer in India |
| DIN 2631 PN6 Weld Neck Pipe Flanges Supplier in Mumbai | Duplex Steel DIN 2631 PN6 Weld Neck Flanges |
| 4 inch Stainless Steel DIN 2631 PN6 Weld Neck Flange | DIN 2631 PN6 Weld Neck RF Flanges Stockholder |
| DIN 2631 PN6 Welding Neck Flanges Supplier in Mumbai | MS DIN 2631 PN6 Weld Neck Flange |
| 30 inch DIN 2631 PN6 Weld Neck Flange Dealer | Raised Face DIN 2631 PN6 Weld Neck Flanges Manufacturer |
| 8 Inch DIN 2631 PN6 Welding Neck Pipe Flanges | DIN 2631 PN6 Weld Neck Flanges Stockist |
| Carbon Steel Raised Face DIN 2631 PN6 Weld Neck Flange Stockist | Duplex Steel DIN 2631 PN6 WNRF Flanges Supplier in Mumbai |
| ASME SA105N Raised Faced DIN 2631 PN6 Weld Neck Flanges | 18 inch Carbon Steel DIN 2631 PN6 Weld Neck Flange |
| DIN 2631 PN6 Weld Neck Pipe Flanges Wholesaler | DIN 2631 PN6 WNRF Flanges Supplier |
| DIN 2631 PN6 Large Diameter Weld Neck Flange | 30 Inch DIN 2631 PN6 Weld Neck Pipe Flange Dimensions |
| DIN 2631 PN6 WNRF Flanges Distributor in Mumbai | Flat Face DIN 2631 PN6 Weld Neck Flanges Exporter |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
