Harsh Flanges stands out as a top-notch manufacturer and supplier of DIN 2527 PN16 Blind Flanges, proudly based in Mumbai, India. They cater to both local and international markets with a focus on excellence and precision. With years of expertise under their belt and a strong commitment to quality, Harsh Flanges delivers durable, high-performance flanges that meet strict industrial standards. These blind flanges are perfect for sealing the ends of pipes in pressure systems and come in a range of materials and sizes. The company is dedicated to timely deliveries, competitive pricing, and customer-centric services, making them a reliable choice for clients in the oil & gas, petrochemical, power, and water treatment sectors.
When it comes to manufacturing DIN 2527 PN16 Blind Flanges, they use materials like carbon steel (ASTM A105), stainless steel (SS304, SS316), and various alloy steels. The composition includes elements such as carbon, manganese, chromium, nickel, and silicon, all aimed at boosting corrosion resistance and strength. On the mechanical side, these flanges boast a tensile strength ranging from 485 to 620 MPa, a yield strength of about 250 MPa, and a minimum elongation of 20%. Designed for systems that operate at 16 bar pressure, they are well-suited for moderate temperature applications, offering excellent durability, weldability, and sealing performance in industrial pipeline systems.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Screws | Weight (7,85 Kg/dm3) | ||||
|---|---|---|---|---|---|---|---|
| D | b | k | Number | Thread | d2 | Shape B | |
| Kg | |||||||
| 15 | 95 | 14 | 65 | 4 | M 12 | 14 | 0,72 |
| 20 | 105 | 16 | 75 | 1,01 | |||
| 25 | 115 | 16 | 85 | 1,23 | |||
| 32 | 140 | 16 | 100 | M 16 | 18 | 1,8 | |
| 40 | 150 | 16 | 110 | 2,09 | |||
| 50 | 165 | 18 | 125 | 2,88 | |||
| 65 | 185 | 18 | 145 | 3,66 | |||
| 80 | 200 | 20 | 160 | 8 | 4,77 | ||
| 100 | 220 | 20 | 180 | 5,65 | |||
| 125 | 250 | 22 | 210 | 8,42 | |||
| 150 | 285 | 22 | 240 | M 20 | 22 | 10,4 | |
| 200 | 340 | 24 | 295 | 12 | 16,1 | ||
| 250 | 405 | 26 | 355 | M 24 | 26 | 24,9 | |
| 300 | 460 | 28 | 410 | 35,1 | |||
| 350 | 520 | 30 | 470 | 16 | 47,8 | ||
| 400 | 580 | 32 | 525 | M 27 | 30 | 63,5 | |
| 500 | 715 | 36 | 650 | 20 | M 30 | 33 | 102 |
Harsh Flanges, a leading supplier in Mumbai, India, offers an extensive selection of DIN 2527 PN16 Blind Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
DIN 2527 PN16 Blind Flanges primarily serve to seal the ends of piping systems and pressure vessel openings, ensuring a secure seal and maintaining system integrity. They find common use in industries like oil & gas, petrochemicals, chemical processing, water treatment, and power generation. These flanges are particularly advantageous for systems that may require future extensions or maintenance access, as they can be easily removed or replaced. Their capability to handle pressures up to 16 bar makes them ideal for medium-pressure applications, ensuring safety, reliability, and efficient performance in critical industrial settings.
Yes, we offer custom sizes for DIN 2527 PN16 Blind Flanges to meet specific project needs. Our team at Harsh Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@harshflanges.co.in.
| NPS NPS (inch) | |||||
|---|---|---|---|---|---|
| Diammeter of Flange (inch) | No. of Bolts | Diammeter of Bolts (inch) | Diammeter of Bolt Holes (inch) | Bolt Circle (inch) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
| Carbon Steel Raised Face DIN 2527 PN16 Blind Flange Stockist | Duplex Steel DIN 2527 PN16 BLRF Flanges Supplier in Mumbai |
| DIN 2527 PN16 Blind Pipe Flanges Supplier in Mumbai | Duplex Steel DIN 2527 PN16 Blind Flanges |
| DIN 2527 PN16 Blind FF Flange Supplier | Suppliers of DIN 2527 PN16 Blind Flange |
| DIN 2527 PN16 Blind Flange Dimensions | Raised Face DIN 2527 PN16 Blind Flange Manufacturer |
| Nickel Alloy DIN 2527 PN16 Blind Flange | Mild Steel DIN 2527 PN16 Blind Flange |
| DIN 2527 PN16 Blind Flange Manufacturer | Flat Face DIN 2527 PN16 Blind Flange Manufacturer |
| Stainless Steel DIN 2527 PN16 Blind Flange | ASTM B564 Raised Faced DIN 2527 PN16 Blind Flanges |
| 18 inch DIN 2527 PN16 Carbon Steel Blind Flange | DIN 2527 PN16 Blind Flange Dimensions in mm |
| Alloy Steel DIN 2527 PN16 Blind Flanges | Copper Nickel DIN 2527 PN16 Blind Flanges at Best Price |
| 8 Inch DIN 2527 PN16 Blind Pipe Flanges | DIN 2527 PN16 Blind Flanges Stockist |
| DIN 2527 PN16 BLRF Flanges Distributor in Mumbai | Flat Face DIN 2527 PN16 Blind Flanges Exporter |
| Raised Face DIN 2527 PN16 Blind Plate Flanges | Titanium DIN 2527 PN16 Blind Flanges |
| DIN 2527 PN16 Large Diameter Blind Flange | 30 Inch DIN 2527 PN16 Blind Pipe Flange Dimensions |
| 30 inch DIN 2527 PN16 Blind Flange Dealer | Raised Face DIN 2527 PN16 Blind Flanges Manufacturer |
| ASME SA105N Raised Faced DIN 2527 PN16 Blind Flanges | 18 inch Carbon Steel DIN 2527 PN16 Blind Flange |
| German Standard DIN 2527 PN16 Blind Flanges | DIN 2527 PN16 Blind Flange Supplier in Mumbai |
| Carbon Steel DIN 2527 PN16 Blind Flange | DIN 2527 PN16 Blind RF Flange Supplier |
| 4 inch Stainless Steel DIN 2527 PN16 Blind Flange | DIN 2527 PN16 Blind RF Flanges Stockholder |
| DIN 2527 PN16 Blind Flanges Supplier in Mumbai | MS DIN 2527 PN16 Blind Flange |
| DIN 2527 PN16 Blind Pipe Flanges Wholesaler | DIN 2527 PN16 BLRF Flanges Supplier |
| DIN 2527 PN16 BLRF Flanges Supplier in Mumbai | Alloy Steel DIN 2527 PN16 Blind Flanges Manufacturer in India |
| DIN 2527 PN16 BLRF Flange Exporter | DIN 2527 PN16 Blind Flange Pressure Ratings |
| DIN 2527 PN16 BLRF Flange Stockist in India | Raised Faced DIN 2527 PN16 Slip-On flanges Dealer in India |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
